FSEZ1317MY全新原装，欢迎来电咨询洽谈，订购！
FSEZ1317 (EZ-PSR for 2-Chip Product)
Primary-Side-Regulation PWM with POWER MOSFET
Integrated
Features
Low Standby Power Under 30mW
High-Voltage Startup
Fewest External Component Counts
Constant-Voltage (CV) and Constant-Current (CC)
Control without Secondary-Feedback Circuitry
Green-Mode: Linearly Decreasing PWM Frequency
Fixed PWM Frequency at 50kHz with Frequency
Hopping to Solve EMI Problem
Cable Compensation in CV Mode
Peak-Current-Mode Control in CV Mode
Cycle-by-Cycle Current Limiting
VDD Over-Voltage Protection with Auto Restart
VDD Under-Voltage Lockout (UVLO)
Gate Output Maximum Voltage Clamped at 15V
Fixed Over-Temperature Protection with
Auto Restart
Available in the 7-Lead SOP and DIP Packages Applications
Battery chargers for cellular phones, cordless
phones, PDA, digital cameras, power tools, etc.
Replaces linear transformers and RCC SMPS Description
This third-generation Primary Side Regulation (PSR)
and highly integrated PWM controller provides several
features to enhance the performance of low-power
flyback converters. The proprietary topology,
TRUECURRENT™, of FSEZ1317 enables precise CC
regulation and simplified circuit design for batterycharger
applications. A low-cost, smaller, and lighter
charger results, as compared to a conventional design
or a linear transformer.
To minimize standby power consumption, the
proprietary green mode provides off-time modulation to
linearly decrease PWM frequency under light-load
conditions. Green mode assists the power supply in
meeting power conservation requirements.
By using the FSEZ1317, a charger can be implemented
with few external components and minimized cost. A
typical output CV/CC characteristic envelope is shown
in Figure 1.
|
