音频运放IC:OPA2134UA

  • 联系人： 王先生/陈小姐/陈先生
  • 电 话： 0755-82549943
  • 手 机:15919934827,13714022523
  • E-mail：qixiudz@163.com
产品详细信息
型号： OPA2134UA 品牌/商标： TI/BB
生产厂家： 马来西亚 产品类别： IC- 音效处理IC
商品介绍：
Product Major Information Vgs(V) BV VTH Ron(10V)   (mΩ) Ron(4.5V) (mΩ) Ron(2.5V) (mΩ)
N/P
Voltage		 Product Name Assembly ID(A)  25℃ PW (W)  25℃ Min Typ Typ Max Typ Max Typ Max
P-20V NCE2305A SOT-23 -4.1 1.7 8 -20 -0.7 37 45 50 60
NCE2305 SOT-23 -4.1 1.7 8 -20 -0.7 45 52 60 75
NCE2301 SOT-23 -3 1 12 -20 -0.7 64 110 89 140
P-30V NCE3407 SOT-23 -4.1 1.4 20 -30 -1.5 55 65 75 95
NCE3407A SOT-23 -4.3 1.5 20 -30 -1.5 50 60 67 85
NCE3401 SOT-23 -4.2 1.2 12 -30 -1 50 55 64 72 95 120
NCE3401A SOT-23 -4.4 1.3 12 -30 -1 45 50 58 65 85 120
NCE9435 SOP-8 -5.1 2.5 20 -30 -1.6 48 55 73 105
NCE9435A SOP-8 -5.3 2.6 20 -30 -1.6 43 49 68 100
NCE4953 SOP-8 -5.1 2.5 20 -30 -1.6 48 55 73 105
NCE4953A SOP-8 -5.3 2.6 20 -30 -1.6 43 49 68 100
NCE3007S SOP-8 -6.5 3.1 20 -30 -1.9 33 46 53 72
NCE4403 SOP-8 -6.1 3 12 -30 -1 38 46 49 61 76 117
NCE4435 SOP-8 -9.1 3.1 20 -30 -1.5 15 20 21 35
NCE3012S SOP-8 -12 3 20 -30 -1.5 10 15 14 25
P40V NCE4005S SOP-8 -5.3 2 20 -40 -1.8 67 80 100 120
NCE4007S SOP-8 -6.2 2.5 20 -40 -1.7 16 25 21 30
NCE4036F TO-220F -36 33 20 -40 -1.7 9 13 11 18
P55V NCE5530 TO-220 -30 90 20 -55 -3 30 40
NCE5530K TO-252 -30 90 20 -55 -3 30 40
N-20V NCE2302 SOT-23 2.9 1 10 20 0.75 30 45 37 59
NCE2312 SOT-23 5 1.25 10 20 0.65 27 33 33 40
NCE2312A SOT-23 5 1.25 10 20 0.65 22 28 27 35
NCE9926 SOP-8 6 1.25 12 20 0.7 26 30 36 40
NCE8205 SOT23-6 4 1.25 10 19.5 0.7 21 27 27 37
NCE8205A TSSOP-8 6 1.5 10 19.5 0.7 21 27 27 37
NCE8205B TSSOP-8 6 1.5 10 20 0.7 16 22 19 27
NCE2012 SOP-8 12 2.5 10 20 0.8 5.5 7 7 9
NCE3420 SOT23 5 1.25 12 20 0.7 19 24 22 27 35 42
N-20V   （ESD） NCE2011E TSSOP-8 11 1.6 10 20 0.8 5.5 7 7 9
NCE2010E TSSOP-8 7 1.5 10 20 0.7 15 21 20 27
NCE2008E TSSOP-8 6 1.5 10 20 0.7 17 24 22 30
N-30V NCE2304 SOT-23 3.6 1.7 20 30 1.5 47 58 61 73
NCE3010S SOP-8 10 2.5 20 30 1.6 7.5 13.5 11 20
NCE3050 TO-220 50 60 20 30 1.6 8 11 10 16*
NCE3050I TO-251 50 60 20 30 1.6 8 11 10 16*
NCE3050K TO-252 50 60 20 30 1.6 8 11 10 16*
NCE3080I TO-251 80 83 20 30 1.6 5 7 7.5 10*
NCE3080L TO-251S 80 83 20 30 1.6 5 7 7.5 10*
NCE3080K TO-252 80 83 20 30 1.6 5 7 7.5 10*
NCE30H10 TO-220 100 110 20 30 1.6 4 5.5 5 8
NCE30H10K TO-252 100 110 20 30 1.6 4 5.5 5 8
NCE30H12 TO-220 120 120 20 30 1.6 2.5 4 3.8 5
NCE30H12K TO-252 120 120 20 30 1.6 2.5 4 3.8 5
NCE30H21 TO-220 210 310 20 30 2.7 2 2.5
N-30V    （ESD） NCE3011E SOP-8 11 2.5 10 30 1.5 7 10 10 14
NCE8601B TSSOP-8 8 1.5 10 30 0.7 15 21 18 26
N-40V NCE40H19 TO-220 190 220 20 40 3 2.4 3.5
NCE40H21 TO-220 210 330 20 40 2.7 2.2 3.2
N-50V BSS138 SOT-23 0.22 0.35 20 50 1.2 1Ω 2Ω 1.2Ω* 3Ω*
N-50V（ESD） BSS138K SOT-23 0.22 0.35 20 50 1.1 1Ω 2Ω 1.3Ω* 3Ω*
N-55V NCE5549 TO-220 49 100 20 55 3 8.4 11
NCE55H11 TO-220 110 180 20 55 3 4.5 6
NCE55H12 TO-220 120 200 20 55 3 4.1 5.5
N-60V 2N7002 SOT-23 0.115 0.2 20 60 1.7 1.1Ω 2Ω 1.3Ω* 3Ω*
2N7002A SOT-23 0.115 0.2 20 60 1.7 2.1Ω 3Ω 2.3Ω* 3.5Ω*
N-60V（ESD） 2N7002K SOT-23 0.3 0.35 20 60 1.7 1Ω 2Ω 1.3Ω* 3Ω*
N-60V NCE6075 TO-220 75 110 20 60 3 9.1 11.5
NCE6075K TO-252 75 100 20 60 3 9.1 11.5
NCE6050 TO-220 50 80 20 60 2.2 17 20
NCE6050K TO-252 50 80 20 60 2.2 17 20
NCE6020K TO-252 20 30 20 60 2.2 37 44
NCE6020L TO-251S 20 30 20 60 2.2 37 44
NCE6003 SOT-23 3 1.7 20 60 1.5 85 105 95 125
NCE3055 SOT-89 3 1.7 20 60 1.5 85 105 95 125
NCE6005S SOP-8 4.5 2 20 60 2 38 45
NCE6005R SOT223 5 2 20 60 2 38 45
NCE60H15 TO-220 150 220 20 60 3 3.6 4.5
NCE60H21 TO-220 210 330 20 60 3 2.6 4
N-70V NCE7075 TO-220 75 110 20 70 3 9.5 12
NCE7075K TO-252 75 100 20 70 3 9.5 12
NCE7080 TO-220 78 150 20 70 3 6.3 8
N-75V NCE7560K TO-252 60 140 20 75 3 6.8 8.5
NCE7559K TO-252 59 130 20 75 3 7.2 8.5
NCE7578 TO-220 78 160 20 75 2.85 7 8.5
NCE7580 TO-220 80 170 25 75 2.85 6.5 8
NCE7580D TO-263 80 170 25 75 2.85 6.5 8
NCE7580T TO-247 80 180 25 75 2.85 6.5 8
NCE75H14 TO-220 140 260 20 75 3 5.1 5.8
NCE75H21T TO-247 210 330 20 75 3 2.9 4
NCE75H21 TO-220 210 310 20 75 3 3.5 4.5
NCE75H26T TO-247 260 385 20 75 3 2.3 3
NCE75H35T TO-247 350 460 20 75 3 1.9 2.6
N-80V NCE8098 TO-220 98 180 20 80 3 6.5 8
NCE80H11 TO-220 105 200 20 80 3 6.3 8
NCE80H11D TO-263 105 200 20 80 3 6.3 8
NCE80H12 TO-220 120 220 20 80 3 4.9 6
N-85V NCE8580 TO-220 80 170 20 85 2.85 6.8 8.5
NCE8580ST TO-220 80 170 20 85 2.85 6.8 8.5
NCE85H15T TO-247 150 280 20 85 2.85 3.9 4.8
NCE85H15 TO-220 150 270 20 85 2.85 4 4.8
NCE85H21T TO-247 210 330 20 85 3 3.2 4.5
NCE85H21 TO-220 210 310 20 85 3 3.7 5
N-100V NCE0128D TO-263 28 150 20 100 3.2 14 18
NCE0106R SOT-223 6 3 20 100 3.2 110 140
NCE0106Z TO-92 6 3 20 100 3.2 110 140
NCE0110K TO-252 9.6 30 20 100 3.2 108 140
NCE0117 TO-220 17 55 20 100 3.2 56 70
NCE0140K TO-252 40 140 20 100 3 14 17
NCE0140KA TO-252 40 140 20 100 1.1 14 17
NCE0157A TO-220 57 160 20 100 3 14 17
NCE0157 TO-220 57 170 20 100 3 12 16
NCE0157T TO-247 57 180 20 100 3 11.7 16
NCE0159 TO-220 59 180 20 100 3 11 15
NCE0170 TO-220 70 190 20 100 3 10.5 14
NCE01H10 TO-220 100 200 20 100 3 9.9 13
NCE01H11 TO-220 110 220 20 100 3 7.8 9
NCE0160S PowerPAK SO-8    60 105 20 100 3.7 12.6 16
NCE01H14 TO-220 140 330 20 100 3.2 5 6.8
NCE01H14D TO-263 140 330 20 100 3.2 5 6.8
NCE01H14T TO-247 140 340 20 100 3.2 4.9 6.8
NCE01H21T TO-247 210 385 20 100 3 3.3 4.3
NCE01H29T TO-247 290 460 20 100 3 2.7 3.5
N-150V NCE1505S SOP-8 5.2 3.5 20 150 3 31 44
NCE1540K TO-252 40 140 20 150 3 35 45
NCE1540KA TO-252 40 140 20 150 1.25 35 45
NCE1540D TO-263 40 150 20 150 1.25 35 45
NCE1550 TO-220 50 220 20 150 3.2 19.5 23
NCE15H11T TO-247 110 385 20 150 3 10 13
NCE1579 TO-220 79 310 20 150 3.1 16 19
NCE1583T TO-247 83 320 20 150 3.1 15.7 18.5
NCE15H10 TO-220 100 370 20 150 3.2 9.8 12
NCE15H15T TO-247 150 460 20 150 3 6.6 8
N-200V NCE0203S SOP-8 3.9 3 20 200 3 56 79
NCE0240 TO-220 40 220 20 200 3.2 36.4 41
NCE0240F TO-220F 40 60 20 200 3.2 36.4 41
NCE0218 TO-220 18 150 20 200 3 64 80
NCE0218D TO-263 18 150 20 200 3 64 80
NCE0218F TO-220F 18 45 20 200 3 64 80
NCE0224D TO-263 24 150 20 200 1.5 64 80
NCE0218K TO-252 18 140 20 200 1.5 65 80
NCE0224K TO-252 24 150 20 200 3.2 63 80
500V
 SJ-MOS		 NCE05N50L TO-251S 5 50 30 500 3 850 900
NCE05N50I TO-251 5 50 30 500 3 850 900
NCE05N50K TO-252 5 50 30 500 3 850 900
NCE05N50F TO-220F 5 31 30 500 3 850 900
NCE05N50 TO-220 5 50 30 500 3 850 900
NCE05N50D TO-263 5 50 30 500 3 850 900
NCE08N50 TO-220 7.8 83 30 500 3 540 600
NCE08N50F TO-220F 7.8 32 30 500 3 540 600
NCE08N50I TO-251 7.8 83 30 500 3 540 600
NCE08N50K TO-252 7.8 83 30 500 3 540 600
NCE08N50D TO-263 7.8 83 30 500 3 540 600
NCE11N50 TO-220 11 125 30 500 3 340 380
NCE11N50F TO-220F 11 33 30 500 3 340 380
NCE11N50D TO-263 11 125 30 500 3 340 380
NCE11N50T TO-247 11 125 30 500 3 340 380
NCE20N50 TO-220 20 208 30 500 3 160 190
NCE20N50F TO-220F 20 34.5 30 500 3 160 190
NCE20N50T TO-247 20 208 30 500 3 155 190
600V
SJ-MOS		 NCE05N60L TO-251S 5 50 30 600 3 850 900
NCE05N60I TO-251 5 50 30 600 3 850 900
NCE05N60K TO-252 5 50 30 600 3 850 900
NCE05N60F TO-220F 5 31 30 600 3 850 900
NCE05N60 TO-220 5 50 30 600 3 850 900
NCE05N60D TO-263 5 50 30 600 3 850 900
NCE08N60 TO-220 7.8 83 30 600 3 540 600
NCE08N60F TO-220F 7.8 32 30 600 3 540 600
NCE08N60I TO-251 7.8 83 30 600 3 540 600
NCE08N60K TO-252 7.8 83 30 600 3 540 600
NCE08N60D TO-263 7.8 83 30 600 3 540 600
NCE11N60 TO-220 11 125 30 600 3 340 380
NCE11N60F TO-220F 11 33 30 600 3 340 380
NCE11N60D TO-263 11 125 30 600 3 340 380
NCE11N60T TO-247 11 125 30 600 3 340 380
NCE20N60 TO-220 20 208 30 600 3 160 190
NCE20N60F TO-220F 20 34.5 30 600 3 160 190
NCE20N60T TO-247 20 208 30 600 3 155 190
650V
SJ-MOS		 NCE05N65L TO-251S 5 50 30 650 3 850 900
NCE05N65I TO-251 5 50 30 650 3 850 900
NCE05N65K TO-252 5 50 30 650 3 850 900
NCE05N65F TO-220F 5 31 30 650 3 850 900
NCE05N65 TO-220 5 50 30 650 3 850 900
NCE05N65D TO-263 5 50 30 650 3 850 900
NCE08N65 TO-220 7.8 83 30 650 3 540 600
NCE08N65F TO-220F 7.8 32 30 650 3 540 600
NCE08N65I TO-251 7.8 83 30 650 3 540 600
NCE08N65K TO-252 7.8 83 30 650 3 540 600
NCE08N65D TO-263 7.8 83 30 650 3 540 600
NCE11N65 TO-220 11 125 30 650 3 340 380
NCE11N65F TO-220F 11 33 30 650 3 340 380
NCE11N65D TO-263 11 125 30 650 3 340 380
NCE11N65T TO-247 11 125 30 650 3 340 380
NCE20N65 TO-220 20 208 30 650 3 160 190
NCE20N65F TO-220F 20 34.5 30 650 3 160 190
NCE20N65T TO-247 20 208 30 650 3 155 190
500V
 SJ-MOS
NF系列		 NCE08NF50 TO-220 7.8 83 30 500 4 570 650
NCE08NF50F TO-220F 7.8 32 30 500 4 570 650
NCE08NF50I TO-251 7.8 83 30 500 4 570 650
NCE08NF50K TO-252 7.8 83 30 500 4 570 650
NCE08NF50D TO-263 7.8 83 30 500 4 570 650
NCE11NF50 TO-220 11 125 30 500 4 370 410
NCE11NF50F TO-220F 11 33 30 500 4 370 410
NCE11NF50D TO-263 11 125 30 500 4 370 410
NCE11NF50T TO-247 11 125 30 500 4 370 410
NCE20NF50 TO-220 20 208 30 500 4 180 210
NCE20NF50F TO-220F 20 34.5 30 500 4 180 210
NCE20NF50T TO-247 20 208 30 500 4 180 210
600V
 SJ-MOS
NF系列		 NCE08NF60 TO-220 7.8 83 30 600 4 570 650
NCE08NF60F TO-220F 7.8 32 30 600 4 570 650
NCE08NF60I TO-251 7.8 83 30 600 4 570 650
NCE08NF60K TO-252 7.8 83 30 600 4 570 650
NCE08NF60D TO-263 7.8 83 30 600 4 570 650
NCE11NF60 TO-220 11 125 30 600 4 370 410
NCE11NF60F TO-220F 11 33 30 600 4 370 410
NCE11NF60D TO-263 11 125 30 600 4 370 410
NCE11NF60T TO-247 11 125 30 600 4 370 410
NCE20NF60 TO-220 20 208 30 600 4 180 210
NCE20NF60F TO-220F 20 34.5 30 600 4 180 210
NCE20NF60T TO-247 20 208 30 600 4 180 210
650V
 SJ-MOS
NF系列		 NCE08NF65 TO-220 7.8 83 30 650 4 570 650
NCE08NF65F TO-220F 7.8 32 30 650 4 570 650
NCE08NF65I TO-251 7.8 83 30 650 4 570 650
NCE08NF65K TO-252 7.8 83 30 650 4 570 650
NCE08NF65D TO-263 7.8 83 30 650 4 570 650
NCE11NF65 TO-220 11 125 30 650 4 370 410
NCE11NF65F TO-220F 11 33 30 650 4 370 410
NCE11NF65D TO-263 11 125 30 650 4 370 410
NCE11NF65T TO-247 11 125 30 650 4 370 410
NCE20NF65 TO-220 20 208 30 650 4 180 210
NCE20NF65F TO-220F 20 34.5 30 650 4 180 210
NCE20NF65T TO-247 20 208 30 650 4 180 210
1200V NPT IGBT NCE10G120 TO-220 10 138 25 1200 5.5 2.0V 2.5V
NCE15G120 TO-220 15 138 25 1200 5.5 2.0V 2.5V
NCE15GD120 TO-220 15 138 25 1200 5.5 2.0V 2.5V
NCE15G120T TO-247 15 220 25 1200 5.5 2.0V 2.5V
NCE15GD120T TO-247 15 220 25 1200 5.5 2.0V 2.5V
NCE20G120T TO-247 20 298 25 1200 5.5 2.0V 2.5V
NCE20GD120T TO-247 20 298 25 1200 5.5 2.0V 2.5V
NCE25G120T TO-247 25 312 25 1200 5.5 2.0V 2.5V
NCE25GD120T TO-247 25 312 25 1200 5.5 2.0V 2.5V
NCE30G120T TO-247 30 339 25 1200 5.5 2.0V 2.5V
NCE30GD120T TO-247 30 339 25 1200 5.5 2.0V 2.5V
NCE35G120T TO-247 35 368 25 1200 5.5 2.0V 2.5V
NCE35GD120T TO-247 35 368 25 1200 5.5 2.0V 2.5V
NCE40G120T TO-247 40 417 25 1200 5.5 2.0V 2.5V
NCE40GD120T TO-247 40 417 25 1200 5.5 2.0V 2.5V
NCE15G120P TO-3P 15 220 25 1200 5.5 2.0V 2.5V
NCE15GD120P TO-3P 15 220 25 1200 5.5 2.0V 2.5V
NCE20G120P TO-3P 20 298 25 1200 5.5 2.0V 2.5V
NCE20GD120P TO-3P 20 298 25 1200 5.5 2.0V 2.5V
NCE25G120P TO-3P 25 312 25 1200 5.5 2.0V 2.5V
NCE25GD120P TO-3P 25 312 25 1200 5.5 2.0V 2.5V
NCE30G120P TO-3P 30 339 25 1200 5.5 2.0V 2.5V
NCE30GD120P TO-3P 30 339 25 1200 5.5 2.0V 2.5V
NCE35G120P TO-3P 35 368 25 1200 5.5 2.0V 2.5V
NCE35GD120P TO-3P 35 368 25 1200 5.5 2.0V 2.5V
NCE40G120P TO-3P 40 417 25 1200 5.5 2.0V 2.5V
NCE40GD120P TO-3P 40 417 25 1200 5.5 2.0V 2.5V
